LK Die Casting Machine Energy Saving Zinc Melting Furnace

LK Die Casting Machine Energy Saving Zinc Melting Furnace

Name: LK Die Casting Machine Energy Saving Zinc Melting Furnace
Brand: Foshan Zhenyang Automation Science And Technology Co., Ltd.
Price: 5000.0 USD
Availability: InStock

5000.0 USD ($)/Set

Get a Price/Quote

Product Details:

Features Energy efficient, automatic temperature control, low maintenance
Accuracy 3C
Control System PID Temperature Controller
Cooling System Forced Air Cooling
Production Capacity 500-1500 kg/h
Frequency 50/60 Hz
Model No LK-ZM-23K
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LK Die Casting Machine Energy Saving Zinc Melting Furnace Price And Quantity

Price 5000.0 USD ($)/Set
Minimum Order Quantity 1 Set

Door Opening Manual/Automatic (Optional)
Applicable Metal Zinc alloys
Safety Features Over-temperature protection, emergency stop switch
Display Digital temperature display
Insulation High-density ceramic fiber
Energy Consumption Low power/high efficiency
Heating Element Type High-temperature electric resistance
Chamber Material Heat-resistant alloy steel
Furnace Capacity 300 kg (customizable)
Melting Cycle Time Within 50-60 minutes per batch

LK Die Casting Machine Energy Saving Zinc Melting Furnace Product Specifications

Technology Energy Saving Die Casting Technology
Production Capacity 500-1500 kg/h
Frame Type Welded Heavy Duty Frame
Weight (kg) 1500 kg
Motor Power 2.5 HP
Model No LK-ZM-23K
Frequency 50/60 Hz
Product Type Zinc Melting Furnace
Accuracy 3C
Color Grey & Orange
Features Energy efficient, automatic temperature control, low maintenance
Cooling System Forced Air Cooling
Pressure Standard (Zinc Melting Furnace does not require hydraulic pressure)
Surface Treatment Heat Resistant Paint Coating
Control System PID Temperature Controller
Power Rating 23 kW
Machine Type Die Casting Melting Furnace
Voltage 380 V
Dimension (L*W*H) 2100 x 1200 x 1850 mm
Connectivity Options Digital Control Panel
Power Source Electric
Operating Temperature Up to 750C
Lubricating System Automatic Lubrication System
Operating Type Automatic
Power 23 kW
Usage & Applications Zinc alloy melting for die casting process
Noise Level < 75 dB(A)
Drive Electric Motor Drive

Door Opening Manual/Automatic (Optional)
Applicable Metal Zinc alloys
Safety Features Over-temperature protection, emergency stop switch
Display Digital temperature display
Insulation High-density ceramic fiber
Energy Consumption Low power/high efficiency
Heating Element Type High-temperature electric resistance
Chamber Material Heat-resistant alloy steel
Furnace Capacity 300 kg (customizable)
Melting Cycle Time Within 50-60 minutes per batch

LK Die Casting Machine Energy Saving Zinc Melting Furnace Trade Information

FOB Port Foshan
Payment Terms Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cash Against Delivery (CAD), Western Union
Supply Ability 60 Set Per Month
Delivery Time 25 Days
Sample Available No
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Packaging Details Standard Exporting Package
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India
Certifications CE Certificate

Product Description

LK Die Casting Machine Energy Saving Zinc Melting Furnace

Machine Tonnage	DC88T	DC160T	DC200T
Melting Pot Capacity	450Kg	550Kg	800Kg
Power	24KW	30KW	45KW
Melting Speed	180Kg/h	200Kg/h	20Kg/h
Melting Electricity Consumption	About 10KW.H	About 10KW.H	About 18KW.H
Temperature Holding Electricity Consumption	About 3-5KW.H	About 5-8KW.H	About 8-12KW.H
Average Daily Electricity Consumption	About 250KW.H	About 250KW.H	About 320-400KW.H

(1) Adopt infrared wave heating technology,the heating elements put inside melting pot;with less heat loss,low defect rate and high thermal efficiency,which could save at least 30% electricity and the melting speed is faster than electric resistance furnace.

(2) Melting pot made with 6mm thickness 316L stainless steel,the service life is longer.

(3) Adopt high quality heating element;the heat distribution is uniform,which could ensure consistant temperature inside melting pot and stable product quality.

(4) Use high grade voltage regulator;without any PCB,the circuit failure rate is much lower and the maintenance is very easy.

(5) Namometer thermal insulation material could hold temperature effectively and reduce burning loss and slag.

(6) Furnace operation and maintenance is very easy.

Precision and Efficiency In Zinc Melting

Engineered using cutting-edge energy-saving die casting technology, the LK-ZM-23K furnace guarantees efficient zinc alloy melting with minimal energy consumption. Its PID temperature controller ensures stabilized output and precise melting cycles, enhancing productivity and material quality. The welded heavy-duty frame and heat-resistant paint provide structural durability, making it a preferred choice for demanding production environments.

Enhanced Safety and Reliability

Operator safety and machine protection are prioritized with built-in over-temperature protection and an emergency stop switch. Manual or automatic door options, high-density ceramic fiber insulation, and a forced air cooling system all contribute to safe, stable, and seamless operation. The digital display allows real-time monitoring, ensuring confidence and control during the zinc melting process.

Customizable Capacity and User-Friendly Operation

The LK-ZM-23K accommodates diverse production needs with a standard 300 kg capacity, customizable as needed. The automatic operation and digital control panel streamline the workflow, while the automatic lubrication system minimizes maintenance. Designed for manufacturers, exporters, and suppliers, this furnace offers consistent performance and ease of use, suitable for medium to high production volumes.

FAQ's of LK Die Casting Machine Energy Saving Zinc Melting Furnace:

Q: How does the LK Zinc Melting Furnace enhance energy efficiency during operation?

A: By utilizing a high-temperature electric resistance heating element and high-density ceramic fiber insulation, the furnace significantly reduces energy consumption while maintaining rapid heating cycles. The PID temperature controller further optimizes power usage during the zinc melting process.

Q: What safety measures are integrated into the zinc melting furnace?

A: The furnace is equipped with over-temperature protection and an emergency stop switch to safeguard operators and equipment. Additionally, the durable chamber, insulated with ceramic fiber, minimizes heat loss and external risk factors during operation.

Q: When should the furnace's melting chamber be accessed, and what are the door options?

A: Access to the melting chamber is recommended only during loading, unloading, or maintenance, aligning with safety protocols. The furnace offers both manual and automatic door opening systems to suit different operational preferences.

Q: Where is this zinc melting furnace best utilized?

A: Designed for die casting foundries and industrial facilities, the LK-ZM-23K is ideal for upstream zinc alloy melting processes in manufacturing, especially where high capacity and energy efficiency are crucial.

Q: What is the process for operating the furnace, and how is temperature managed?

A: Operation is largely automatic via a digital control panel. The PID temperature controller precisely regulates and maintains the desired melting temperature, which can reach up to 750C, with real-time monitoring through a digital display system.

Q: Which benefits does the LK-ZM-23K offer compared to traditional zinc melting furnaces?

A: It provides faster melting cycles (50-60 minutes per batch), higher energy efficiency, automated controls, increased safety, and lower noise output, all packaged in a robust, heavy-duty frame that requires minimal maintenance.
