Real Time Control Die Casting Machine

Product Description

With economy globalization,the demand of precise and high quality die casting parts is increasing. In order to solve this problem effectively,we develops the advanced real-time control die casting machine. In addition to the curve display function,the embedded real time control system is also equipped with big-flow electrohydraulic valves,which can feedback the injection speed precisely.The provision of injection speed control curve in different phases,constant acceleration function in low-speed phase,brake function in fast injection phase,could provide customers with powerful die casting control technology and satisfy the complex and high quality die casting production requirement.

• Real Time Control Die Casting Machine Advantage
• Whole process close loop control to ensure product quality repeatability
• Multi-stage speed control to provide flexible process control setting
• Constant acceleration slow speed injection to reduce porosity defect
• High speed end brake function to reduce flash and improve product surface quality
• There are 5 stages to control the slow speed
• Injection start and slow speed inject no pressure fluctuation to avoid air trapped
• Switching time from slow speed to high speed15ms
• The shortest speed-raising time to meet the perfect process and reduce the trapped air
• The system could provide several deceleration way
• High speed brake function to avoid knocking force and flash to prolong mould service life

Customizable Performance and Versatility

Every RTCD1200 Die Casting Machine is engineered to match specific production needs. With adjustable shot capacity, clamping force, and platen dimensions, it seamlessly adapts to various applications in aluminum, zinc, or magnesium die casting. Cross-industry users can count on robust construction and high efficiency for delivering consistent, high-quality castings.


Advanced Injection System for Precision

Utilizing a high-pressure injection mechanism with programmable control, the RTCD1200 ensures accurate dosing and reliable mold filling every cycle. The hydraulic/multi-point locking and water-cooled systems ensure process stability and uniform part quality, even under continuous, demanding production schedules.


Efficiency and User-Friendly Operation

The machine is built for speed and simplicity. With fast machine cycle times, automatic lubrication, real-time monitoring, and smart standby modes, it cuts energy waste and operating costs. The intuitive HMI touchscreen provides comprehensive process control and monitoring, supporting both novice and experienced operators.
