Used Yizumi 800t Cold Chamber Die Casting Machine

Used Yizumi 800t Cold Chamber Die Casting Machine

100000-150000 USD ($)/Set

Get a Price/Quote

Product Details:

Product Type Other
Technology Other
Power Source Electricity
Operating Type Manual
Power 45000 Watt (w)
Pressure 16 mpa
Surface Treatment Painted
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Used Yizumi 800t Cold Chamber Die Casting Machine Price And Quantity

Price 100000-150000 USD ($)/Set
Minimum Order Quantity 1 Set
Price Range 100000.00 - 200000.00 USD ($)/Set

Used Yizumi 800t Cold Chamber Die Casting Machine Product Specifications

Production Capacity 1 Pcs/min
Color Grey
Usage & Applications Aluminium Die Casting
Technology Other
Weight (kg) 40000 Kilograms (kg)
Dimension (L*W*H) 9000*2420*3220 Millimeter (mm)
Pressure 16 mpa
Operating Type Manual
Surface Treatment Painted
Warranty Half Year
Power 45000 Watt (w)
Product Type Other
Power Source Electricity

Used Yizumi 800t Cold Chamber Die Casting Machine Trade Information

FOB Port Guangzhou
Payment Terms Cash Against Delivery (CAD) Letter of Credit (L/C) Letter of Credit at Sight (Sight L/C) Telegraphic Transfer (T/T) Western Union
Supply Ability 10 Set Per Month
Delivery Time 15 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details Standard Exporting Package
Certifications CE Certificate

Product Description

Used Yizumi Dc800t Cold Chamber Die Casting Machine

Superior Injection System

Yizumi superior non-floating piston injection system has a low malfunction rate.

Central Lubrication System

The toggles are equipped with an automatic central lubrication system that allows separate adjustments of the lubrication interval and oil volume and improves the lifespan and reliability of the machine.

Highly Stable Toggle System

The high-rigidity mold opening and closing mechanism meets the requirements of high-speed machines and it is resistant to impacts and has long lifespan. In addition, the fast clamping system is a standard feature for the purpose of high-speed production.

Precise Hydraulic Control System

Multi-level electrically operated proportional pressure and flow control, as well as low-pressure mold protection is available.

Higher Efficiency

The injection system and extremely fast clamping system, built according to the new structural design of advanced foreign die casting machines, are much more reliable than traditional die casting machines and achieve high-speed production and higher output.

Used YIZUMI DC800T Cold Chamber Die Casting Machine Technological Date

ITEM	Unit	DC800T
Locking Force	KN	8000
Locking Stroke	mm	760
Die Height (Min. - Max.)	mm	400-950
Platen Size (HxV)	mm	1420*1420
Space Between Tie bars	mm	930*930
Tie Bar Diameter	mm	180
Injection Force	KN	645
Injection Stroke	mm	760
Plunger Diameter	mm	80/90/100
Injection Weight (Al)	KG	7.1/9/11.1
Casting Pressure (Intensify)	KN	128/101/82
Casting Area	cm	620/784/963
Max Casting Area(40Mpa)	cm	2000
Injection Position	mm	0,-250
Ejector Force	KN	300
Ejecting Stroke	mm	200
Motor Power	KW	45
System Working Pressure	MPa	16
Oil Tank Capacity	L	1200
Machine Weight	Kg	40000
Machine Dimensions (LxWxH)	mm	900024203220
